Colorado Midland Railway Engineering Report
« on: December 22, 2014, 11:46:41 AM »
0
I've decided to enter the Railwire micro-layout pool with something a little different...  I have a 2.5' x 5' space currently occupied by my son's Apex, NC CSX layout.  He's lost interest in it so it can be recycled.  All the Unitrack, structures, trees, and details will be removed, by the fine 2.5' x 5' benchwork will be salvaged.

The layout will be based on the Leadville, CO area, where the Colorado Midland and Denver & Rio Grande had standard gauge trackage (and the Denver, South Park and Pacific-later Denver, Leadville, and Gunnsion, then Colorado & Southern had narrow gauge).  The era will be very flexible, so from the mid-late 1890s through the beginning of World War I.

For those not familiar with the Midland, it was a standard gauge railroad built like a narrow gauge one.  It headed west out of Colorado Springs through Ute Pass and Eleven Mile Canyon and across the South Park.  From the South Park to Buena Vista via Trout Creek Pass, it paralleled the DSP&P narrow gauge.  From Buena Vista it turned north to Leadville following the Arkansas River (Leadville eventually ended up on a branchline connecting at the now gone Arkansas Junction).  From just north of Leadville the railroad began its assault of the Continental Divide, tunneling under Hagerman pass at just shy of 12,000 feet above sea level.  From there it descended the Fryaing pan River valley, eventually reaching Glenwood Springs.  It operated a branch from Glenwood to Aspen.

My version will use what can be found of the Roundhouse/Athearn old-timey stuff like the 2-8-0s and the 36' cars.  It won't be exact from an equipment perspective, but I'm really looking at a vignette more than anything.

Track will be code 55.  Yeah, code 40 (or lighter) is probably more realistic, but code 55 will do fine.

Two plans that come to mind:

The first is the Laurel Highland Railroad:

https://books.google.com/books?id=sKUetsS-SpMC&pg=PA42&lpg=PA42&dq=laurel+highland+track+plan&source=bl&ots=O15ESacOKY&sig=yarLV1cYeiJXS62RxpLJNuPPZCg&hl=en&sa=X&ei=PkqYVPjsO8K2oQSg8oGICQ&ved=0CB4Q6AEwAA#v=onepage&q=laurel%20highland%20track%20plan&f=false

The second is the Rock Ridge Central built by Model Railroader in 2002.  Both are HO 4x8s, but can fit nicely in 2.4 x 5 in N scale.

The downside to the Laurel Highland plans are the curved turnouts which are much tighter than the Atlas ones.

The other huge challenge will be equipment.  Athearn made a few RTR Colorado Midland items, but they're impossible to find:



Consequently, I will need lots of custom decals...  Any ideas or pointers?
